Danfoss 023Z5029 Hermetic Filter Drier
Danfoss 023Z5029 Hermetic Filter Drier
Product Description:
-
- They are specialized type of filter drier used in refrigeration and air conditioning systems, typically found in hermetic systems where the compressor and the rest of the system are sealed in a single, enclosed unit.
- They plays a critical role in maintaining the integrity and efficiency of the system by filtering contaminants and removing moisture from the refrigerant.
- It is a specific type of filter drier designed for use in hermetically sealed refrigeration systems.
- It refer to the sealed and airtight nature of the compressor and motor in refrigeration and air conditioning systems.
- It plays a crucial role in these systems by filtering out contaminants and removing moisture from the refrigerant.
Product Specification:
| Acid capacity [g] | 3.11 g |
| Acid capacity [oz] | 0.11 oz |
| Activated alum/Molec sieve [%] | 20% / 80% |
| Approval | UL |
| Body material | Steel |
| Braket | No |
| Brand | ELIMINATOR |
| Category | Art. 3, par. 3 |
| Connection material | Copper |
| Core | Solid core |
| Core Size code | 16 cu.in. |
| Drying Cap[Drops of Water]24°C | R134a: 443 R290: 350 R32: 373 R404A: 461 R407C: 430 R410A: 401 R507: 483 |
| Drying Cap[Drops of Water]52°C | R134a: 405 R290: 280 R32: 343 R404A: 437 R407C: 396 R410A: 356 R507: 434 |
| Flow Capacity KW | R134a: 18.1 R290: 21.8 R32: 27.6 R404A: 12.7 R407C: 18.6 R410A: 18.9 R507: 12.4 |
| Flow Capacity TR | R134a: 5.2 R290: 6.2 R32: 7.9 R404A: 3.6 R407C: 5.3 R410A: 5.4 R507: 3.5 |
| Flow direction indicator | Label printed 1-way arrow |
| Fluid Group | 2 |
| Inlet 1 connection size [in] | 3/8 in |
| Inlet connection type | Solder, ODF |
| LiqCap Cond (ARI 710-2009)[SI] | Delta p=0.07bar tliq= 30°C tvap=-15°C |
| LiqCapCond (ARI 710-2009)[IMP] | DELTA P=1PSI tliq= 86°F tvap=5°F |
| Lubricants compatibility | Oilfree applications |
| Max. Working Pressure [bar] | 46 bar |
| Max. Working Pressure [psig] | 667 psig |
| Net volume [foz US] | 7.63 oz |
| Net volume [l] | 0.226 L |
| Oil free refrigerants | R1234ze(E) R134a R513A R515A |
| Outlet 1 connection size [in] | 3/8 in |
| Outlet connection type | Solder, ODF |
| Product family name | DCL |
| Product group | Filter driers |
| Product name | Hermetic filter drier |
| Quantity per packing format | 12 pc |
| Refrigerant oil compatibility | Oilfree applications R1234ze(E) R134a R513A R515A |
