Mean Well ELG20042A LED Driver
Mean Well ELG20042A LED Driver
LED drivers control and maintain the current supplied to the LEDs. Many LEDs require a constant current to operate optimally, and LED drivers can deliver this by adjusting the voltage to accommodate changes in the LED’s forward voltage drop.
Product Specification:
|
Brand
|
Mean Well
|
||
|
Item number
|
ELG-200-42A
|
||
|
Series
|
ELG-200
|
||
|
Description
|
AC-DC Single output LED Driver Mix Mode (CV+CC) with PFC; Output 42Vdc at 4.76A; cable output; Adjust CC with Potentiometer
|
||
|
Application
|
LED EN 61347
|
||
|
Technology
|
AC/DC
Constant Current C.C.
Constant Power C.P.
Constant Voltage C.V.
|
||
|
Power Format
|
Box Type – Enclosed
Enclosed Metal housing
|
||
|
Output Power (W)
|
200
|
||
|
Output Voltage (V)
|
42
|
||
|
Output Current (A)
|
4.76
|
||
|
Input Voltage (V)
|
100 – 305
110/230 universal input
|
||
|
IP Rating
|
IP65
|
||
|
Width (mm)
|
71
|
||
|
Height (mm)
|
37.5
|
||
|
Depth (mm)
|
244
|
||
|
Control Signals
|
Potentiometer
|
||
|
Dimming Technology
|
Analog
Potentiometer
|
||
|
Housing Type
|
Metal
|
