ONSEMI NTLUS3C18PZTBG Mosfet
ONSEMI NTLUS3C18PZTBG Mosfet
Product Description:
- It is a type of field-effect transistor (FET) that uses a metal-oxide-semiconductor structure to control the flow of electrical current. They are widely used in electronic devices and integrated circuits due to their high efficiency, fast switching speeds, and ability to handle high power levels.
-
A MOSFET (Metal-Oxide-Semiconductor Field-Effect Transistor) is a high-performance semiconductor device used to amplify or switch electronic signals in modern electronic circuits.
-
It operates by controlling the flow of current between the drain and source terminals through an electric field applied to the gate terminal, offering fast switching speeds, high efficiency, and low power loss.
-
MOSFETs are widely used in power electronics, signal processing, microcontrollers, motor drives, and switching power supplies, making them integral to both industrial and consumer electronics.
-
They are available in N-channel and P-channel types, each suitable for different circuit configurations, and are valued for their high input impedance, thermal stability, and compact size.
Product Specification:
- Manufacturer : ONSEMI
- Vds – Drain-Source Breakdown Voltage : 12 V
- Id – Continuous Drain Current : 7 A
- Rds On – Drain-Source Resistance : 24 mOhms
- Vgs – Gate-Source Voltage : – 8 V, + 8 V
- Minimum Operating Temperature : – 55 C
- Maximum Operating Temperature : + 150 C
- Height : 1.5 mm
- Length : 1.6 mm
- Width : 1.6 mm
- Unit Weight : 4.710 mg
