Pepperl Fuchs LB1103A Frequency Counter Input
Pepperl Fuchs LB1103A Frequency Counter Input
Product Description :
- It is an electronic device used to measure the frequency of an input signal, typically in the form of a periodic waveform. It counts the number of cycles (or events) of a signal over a specified time period and displays the result, typically in Hertz (Hz), which represents the number of cycles per second.
- The input to a frequency counter is typically a periodic signal, which could come from various sources, including oscillators, pulses from a sensor, or digital signals. The counter works by measuring the number of pulses or cycles that occur within a given measurement time.
-
A Frequency Counter Input is a dedicated terminal or module designed to receive and process high-speed pulse or frequency signals from external devices such as encoders, flow meters, proximity sensors, or rotary transducers. It allows digital systems—including PLCs, controllers, and test instruments—to accurately measure the frequency, count pulses, or calculate speed and rate values in real time.
-
These inputs are crucial for applications where timing, rotational speed, or event counting is essential, offering high-resolution data acquisition for industrial automation and control systems.
Product Specification :
- Connection – Backplane bus
- Rated voltage – Ur 12 V DC , only in connection with the power supplies LB9
- Power consumption – 0.6 W
- Interface manufacturer – Specific bus to standard com unit
