Phoenix Contact MINIMCRSLPTB Power Terminal Block
Phoenix Contact MINIMCRSLPTB Power Terminal Block
- A power terminal block is a specific type of terminal block designed to handle high-voltage and high-current electrical connections. Terminal blocks, in general, are modular, insulated blocks or panels used to connect, secure, and organize electrical conductors or wires. Power terminal blocks are design to accommodate larger wire sizes and handle the increased current and voltage levels typically found in power distribution and industrial applications.
Product Specification :
| Width | 6.2 mm |
| Height | 93.1 mm |
| Depth | 102.5 mm |
| Connection method | Screw connection |
| Conductor cross section, rigid min. | 0.2 mm² |
| Conductor cross section, rigid max. | 2.5 mm² |
| Conductor cross section flexible min. | 0.2 mm² |
| Conductor cross section flexible max. | 2.5 mm² |
| Conductor cross section AWG min. | 26 |
| Conductor cross section AWG max. | 12 |
| Stripping length | 12 mm |
| Screw thread | M3 |
