Schneider Electric 48347 Switch Disconnector
Schneider Electric 48347 Switch Disconnector
Product Description :
- This Compact INS160 is a 3 poles non-automatic switch-disconnector with black rotary handle. It is suitable for isolation with positive contact indication, as defined by IEC 60947-1 and IEC60947-3 standards. The operational current is 160A at 415VAC in categories AC22A and AC23A. The rated voltage is 690VAC 50/60Hz or 250VDC. The black rotary handle is designed to offer easy operation and high performance in interruption of currents.
Product Specification:
| Poles description | 4P |
|---|---|
| Network type | AC |
| Network frequency | 50/60 Hz |
| [Ie] rated operational current | 5000 A AC 50/60 Hz 690 V |
| [Ui] rated insulation voltage | 1000 V AC 50/60 Hz conforming to IEC 60947-3 |
| [Uimp] rated impulse withstand voltage | 12 kV conforming to IEC 60947-3 |
| [Icm] rated short-circuit making capacity | 187 kA 220…690 V AC at 50/60 Hz |
| [Ue] rated operational voltage | 690 V AC 50/60 Hz conforming to IEC 60947-3 |
| Breaking capacity code | HA |
| Suitability for isolation | Yes conforming to IEC 60947-3 |
| Contact position indicator | Yes |
| Visible break | No |
| Pollution degree | 4 conforming to IEC 60664-1 |
