Schneider Electric GV2ME08 Motor Circuit Breaker
Schneider Electric GV2ME08 Motor Circuit Breaker
Product Description:
- A Motor Circuit Breaker (MCB) is a specialized type of circuit breaker designed specifically to protect electric motors from various faults, such as overloads, short circuits, and phase failures.
- It provides comprehensive protection for motors by ensuring they operate safely and efficiently while preventing damage from electrical or mechanical faults.
- Motor circuit breakers are often integrated into motor starters or motor control centers.
- They work in conjunction with contactors, thermal overload relays, and other components to provide comprehensive motor protection and control.
- The Schneider Electric GV2ME08 Motor Circuit Breaker is designed for superior motor protection in industrial and commercial settings. With robust construction and reliable performance, this GV2ME08 Motor Circuit Breaker safeguards your motors from overloads and short circuits, ensuring operational safety and efficiency. Schneider Electric’s innovative design guarantees easy installation and maintenance, making it the preferred choice for engineers and technicians.
Product Specification:
| Control type | Push-button |
|---|---|
| [In] rated current | 4 A |
| Thermal protection adjustment range | 2.5…4 A conforming to IEC 60947-4-1 |
| Magnetic tripping current | 51 A |
| [Ith] conventional free air thermal current | 4 A conforming to IEC 60947-4-1 |
| [Ue] rated operational voltage | 690 V AC 50/60 Hz conforming to IEC 60947-2 |
| [Ui] rated insulation voltage | 690 V AC 50/60 Hz conforming to IEC 60947-2 |
| [Uimp] rated impulse withstand voltage | 6 kV conforming to IEC 60947-2 |
| Phase failure sensitivity | Yes conforming to IEC 60947-4-1 |
| Suitability for isolation | Yes conforming to IEC 60947-1 § 7-1-6 |
| Power dissipation per pole | 2.5 W |
| Mechanical durability | 100000 cycles |
| Electrical durability | 100000 cycles for AC-3 at 415 V In |
| Rated duty | Continuous conforming to IEC 60947-4-1 |
| Tightening torque | 1.7 N.m – on screw clamp terminal |
| Width | 45 mm |
| Height | 89 mm |
| Depth | 78.5 mm |
| Net weight | 0.26 kg |
