Schneider Electric LV429407 Voltage Release
Schneider Electric LV429407 Voltage Release
Product Description :
- It refers to a safety mechanism used in electrical systems to automatically disconnect or isolate a device or circuit when the voltage falls below a certain threshold. It is primarily used to protect electrical equipment from malfunction or damage caused by low voltage conditions.
- They are designed to disconnect electrical circuits when the voltage drops below a safe operating level, preventing potential damage to electrical equipment that may occur when operating at insufficient voltage.
Product Specification :
| Operating threshold | 0.35…0.7 x Un opening 0.85 x Un closing |
|---|---|
| Response time | 50 ms |
| Supply holding power | 5 VA |
| Supply inrush power | 10 VA |
| Auxiliary connection terminal | Spring 0.5…1.5 mm² (AWG 20…AWG 16) |
| Wire stripping length | 7 mm |
