Schneider Electric MG17416 Miniature Circuit Breaker
Schneider Electric MG17416 Miniature Circuit Breaker
Product Description :
- It is a device or component use to protect electronic circuits or equipment from temperature-related issues using thermistors. Thermistors are temperature-sensitive resistors that can be use to monitor and control temperature in various applications. They are commonly use in a wide range of applications, including industrial machinery, electronics, HVAC systems, and automotive systems, to prevent overheating and ensure safe operation. They play a crucial role in maintaining the integrity and reliability of equipment by monitoring and controlling temperature variations.
- A Miniature Circuit Breaker (MCB) is an automatic electrical protection device designed to protect electrical circuits from overcurrent, short circuits, and electrical faults. It quickly interrupts the flow of electricity when a fault is detected, preventing damage to wiring, equipment, and reducing fire risk.
Product Specification:
| System Voltage | 240 V 60 V 415 V |
|---|---|
| Mounting Mode | Clip-on |
| Poles description | 1P |
| Interrupt Rating | 10 kA 5 kA 3 kA |
| Network Frequency | 50/60 Hz |
| Curve code | C |
| Magnetic tripping limit | 8.5 x In +/- 20 % AC 12 x In +/- 20 % DC |
| Limitation class | 3 EN/IEC 60947-2 |
| [Ui] rated insulation voltage | 500 V AC EN/IEC 60947-2 |
| [Uimp] rated impulse withstand voltage | 6 kVEN/IEC 60947-2 |
| Contact position indicator | Yes |
| Control Type | Toggle |
| Local signalling | ON/OFF indication |
| Mounting Support | DIN rail |
| 9 mm pitches | 2 |
| Height | 3.2 in (81 mm) |
| Width | 0.7 in (18 mm) |
| Depth | 2.9 in (73 mm) |
