Sigma Valves 24RV16 Relief Valve
Sigma Valves 24RV16 Relief Valve
Product Description :
- It is a critical safety component used in various systems to prevent overpressure conditions. Its primary function is to release excess pressure to protect equipment, systems, or processes from damage or failure.
- It releases excess pressure to prevent damage to equipment or systems due to overpressure conditions.Ensures safe operation of systems by maintaining pressure within specified limits.
- Helps maintain system pressure within a safe operating range, contributing to process stability.
- It protects equipment and personnel from hazardous overpressure conditions.Ensures consistent and safe operation of systems.
Product Specification :
- Piston Movement: Two Position, Normally Closed
- Body Pressure Rating (Inlet Port): 10,000 PSI maximum (690 bar)
- Instrument Media Service: Hydraulic Fluid
- Connection Size: 1/4-18 Female N.P.T. Inlet and Exhaust
- Seal Material: Viton
- Wetted Component Material (Metal): 316 Stainless Steel, 17-4PH SS & Tungsten Carbide
