SKF 5011 CV Cylinder Roller Bearing

SKF 5011 CV Cylinder Roller Bearing

SKF 5011 CV Cylinder Roller Bearing

Product Description :

• It is a type of rolling-element bearing that uses cylindrical rollers to maintain the separation between the bearing races. These bearings are designed to handle heavy radial loads, and they have higher radial load-carrying capacity than ball bearings because of the larger contact area between the rollers and races.
• The rollers are cylindrical in shape, offering greater surface contact compared to ball bearings. Primarily designed to handle radial loads, but they can also withstand some axial loads depending on the bearing design.

Product Specification :

• Bore diameter	55 mm
  Outside diameter	90 mm
  Width	46 mm

• Basic dynamic load rating	190 kN
  Basic static load rating	280 kN
  Reference speed	3 400 r/min
  Limiting speed	4 300 r/min
