Sun RDFALCN Relief Valve
Sun RDFALCN Relief Valve
Product Description :
- It is a safety device used in various industrial and mechanical systems to protect equipment, pipelines, and containers from excessive pressure. Its primary function is to release excess pressure by allowing a controlled flow of fluid (usually gas or liquid) out of the system when the pressure exceeds a predetermined set point.
- This prevents catastrophic failures, explosions, or damage to the system and its components. This helps prevent the pressure from reaching dangerous levels that could cause damage or pose a safety risk.
- The Sun RDFALCN Relief Valve is a high-performance hydraulic pressure control component designed to protect hydraulic systems from overpressure conditions.
- The Sun RDFALCN Relief Valve ensures safe and stable system operation by automatically relieving excess pressure and maintaining preset pressure limits in demanding hydraulic applications.
- Engineered with precision and manufactured to strict quality standards, the Sun RDFALCN Relief Valve delivers accurate pressure regulation, fast response, and reliable performance.
- This valve is widely used in hydraulic power units, industrial machinery, mobile equipment, construction machines, and heavy-duty hydraulic systems where consistent pressure control is essential.
Product Specification :
| Cavity | T-3A |
| Series | 2 |
| Capacity | 50 gpm |
| Maximum Operating Pressure | 5000 psi |
| Factory Pressure Settings Established at | 4 gpm |
| Maximum Valve Leakage at Reseat | 10 drops/min. |
| Response Time – Typical | 2 ms |
| Reseat | >90% of setting |
| Adjustment – No. of CW Turns from Min. to Max. setting | 6 |
| Valve Hex Size | 1 1/8 in. |
| Valve Installation Torque | 45 – 50 lbf ft |
| Adjustment Screw Internal Hex Size | 5/32 in. |
| Locknut Hex Size | 9/16 in. |
| Locknut Torque | 80 – 90 lbf in. |
