Tuthill 807C1 Fuel Transfer Meter
Tuthill 807C1 Fuel Transfer Meter
Product Description:
- The 807C1 is a 3-digit mechanical fuel transfer meter. This meter is equipped with NPT threads and is designed to register 5-20 gallons per minute at +/- 1% accuracy. This model does not include additional installation components.
- The Tuthill 807C1 Fuel Transfer Meter is a precision-engineered device designed to provide accurate fuel measurement, reliable flow monitoring, and efficient fuel transfer operations. The Tuthill 807C1 Fuel Transfer Meter is widely used in industrial, automotive, agricultural, and commercial fuel handling systems where precise fuel dispensing and monitoring are critical.
- Built with high-quality materials and advanced metering technology, the Tuthill 807C1 Fuel Transfer Meter ensures consistent accuracy, long service life, and dependable performance even in demanding environments. This fuel transfer meter is specifically designed to measure diesel, gasoline, and other compatible fuels with high precision, helping operators maintain control over fuel usage and reduce waste.
Product Specification:
| Max Flowrate | 20 |
|---|---|
| Flowrate Range | 5-20 GPM |
| Inlet / Outlet Thread Size (in.) | 1 / 1 |
| Max Operating Pressure (PSI) | 50 |
| Accuracy (+/- %) | 1 |
| Repeatability (+/- %) | 0.38 |
| Display Type | Mechanical |
| Display Digits | 3 |
Dimensions:
| Assembled Product Height x Width x Depth (in.) | N/A x N/A x 4.9 |
|---|---|
| Assembled Product Weight (lbs.) | 4.2 |
| Package Height x Width x Depth (in.) | 7.5 x 7.25 x 10.5 |
| Gross Weight (lbs.) | 5.500 |
Features:
- Versatile Technology – designed with nutating disc technology that is capable of moving rust and small debris that jam and cause damage to other meters
- Cast-Aluminum Construction – built to last with rugged cast-aluminum construction, designed for maximum durability and lifetime corrosion resistance
- Extreme Accuracy – measures fuel within +/- 1% accuracy, ensuring your record-keeping is precise as possible
- Low-Volume Applications – 3-digit counter registers flow rates between 5-20 GPM and up to 99.9 gallons or liters per batch, perfect for equipment with small fuel tanks
- Lifetime Tracking – 5-digit non-resettable counter tracks total volume transferred over lifetime of meter
- 807C1 Digit Mechanical Fuel Transfer Meter 5-20 GPM 3
