Yokogawa FG320 Function Generator
Yokogawa FG320 Function Generator FG320
Product Description :
- Compact tester of vibration, displacement and speed monitoring systems. The tester FG320 represents unique device for configuring and commissioning of rotating machines monitoring systems.
- The tester is able to simulate all types of commonly used sensors of vibration, displacement, eccentricity and speed. Very compact and light device is controlled by common PC/laptop with Windows operating system.
- The Yokogawa FG320 Function Generator FG320 supports multiple waveform outputs, including sine, square, and triangle waves, enabling flexible testing across a wide range of electronic applications.
- With its stable frequency accuracy and low signal distortion, the Yokogawa FG320 Function Generator FG320 ensures reliable and repeatable measurement results.
Product Specification :
DC output
- Voltage scale : ± 22V
- Current scale : 0…24 mA
- Minimum signal increment : 10 mV / 10 µA
AC output
- Frequency scale : 0-20 kHz
- Signal scale : up to 4 V / 12 mA
- Minimum signal increment : 0,1 mV / 1 µA
Selected functions
- Configurable : Ramp
- Speed : Output
- User-defined : Signal
