ENM T40B45 Panel Meter
ENM T40B45 Panel Meter
Product Description:
- A panel meter refers to an instrument that displays a measurement (such as voltage, current, resistance, temperature, or other electrical parameters) on a panel or control board. Panel meters are widely used in various applications where monitoring and displaying specific electrical or physical quantities are essential. They provide a visual representation of the measured values, allowing operators or users to quickly assess the status of a system.
- The ENM T40B45 Panel Meter is a high-precision digital panel meter designed for accurate measurement and display of voltage, current, and other electrical parameters in industrial and commercial applications. This reliable panel meter provides real-time monitoring, ensuring safe and efficient operation of electrical systems, machinery, and control panels.
- Built with a robust housing and advanced electronics, the ENM T40B45 Panel Meter delivers durable, long-lasting performance even in harsh environments. Its easy-to-read display, precision calibration, and wide measurement range make it ideal for use in industrial automation, power distribution, generators, switchgear, and process control systems.
Product Specification:
- Connection Type: Blade Terminal
- Depth: 1.26″ (32mm)
- Dimensions: 1.68 W x 1.68 H x 1.26 D in
- Dimensions, Cutout, Inches: 2 Dia. in
- Display Digit Height: 0.14 in.
- Display Type: Digital
- Function: Hour Meter
- Input Type: Voltage
- Maximum Opening Temperature: +65 °C
- Measurement Range: 0 to 99999.9 hr.
- Measuring Range: 0 to 99999.9 hr
- Minimum Operating Temperature: -30 °C
- Mounting Type:Â Panel Mount
- Number of Digits: 6
- Panel Cut Out: 2 in., 50.8 mm Dia.
- Primary Type: Electromechanical
- Product Header: T40 Series Quartz DC Hour Meter
- Supply Voltage: 10-80 VDC
- Temperature Range: -30 to 65 C
- Type: Electromechanical
