NMB-MAT 5915PC-23T-B30 Axial Fan
NMB-MAT 5915PC-23T-B30 Axial Fan
Product Description :
- It is also known as a propeller fan, is a type of fan that move air in a direction parallel to its rotating axis.
- The design of an axial fan involves blades or impellers mounted on a central hub, similar to an aircraft propeller.
- When the blades rotate, they create airflow by pulling air in along the axis of rotation and then pushing it out in the same direction.
- They are popular due to their ability to move a large volume of air with relatively low power consumption.
Product Specification :
|
Frame Width [mm]
|
150
|
|
Frame Height [mm]
|
172
|
|
Frame Depth [mm]
|
38
|
|
Nominal Voltage [V]
|
230
|
|
Frequency [Hz]
|
50
|
|
Max. Air Flow [CFM]
|
176.5
|
|
Max. Air Flow [m3 per min]
|
5
|
|
Max. Static Pressure [In H2O]
|
0.629
|
|
Max. Static Pressure [Pa]
|
156.8
|
|
Fan Speed [RPM]
|
2700
|
|
Noise [dB]
|
52
|
|
Life Expectancy [L10]
|
25deg.C 100,000 hours
|
|
Bearing Type
|
Ball Bearing
|
|
Starting Voltage [V]
|
145
|
|
Input Power (+10% or -20%) [W]
|
35
|
|
Current [A]
|
0.18
|
|
Mass [g]
|
800
|
